Couplings and Tees There are 27 products.

Showing 1 - 27 of 27 items
  • Compression ring 8mm Conical for LPG Pipe / coupling pieces
    0,36 €
    Compression ring barrel 8mm Biconical for...

    Used in combination with Ø8mm LPG Pipe (Copper / Plastic) and a Ø8 mm swivel to seal an LPG coupling.  Manufacturer code: BA-0002Inner diameter: Ø8mmMaterial: BrassPressure class: 67R-01 Class 1 (max. 30 bar)

    0,36 €
    IN STOCK
  • Compression ring barrel Ø8 mm Asymmetrical for compression coupling
    0,45 €
    Compression ring barrel Ø8 mm Asymmetrical...

    Used in combination with compression fittings and Ø8 mm LPG pipe (Copper / Plastic) to seal an LPG coupling.Asymmetrical: This means that the compression ring only has a conical side on one side. Use this type of compression ring to replace a similar type.  Inner diameter: Ø8mmMaterial: Brass

    0,45 €
    IN STOCK
  • T-piece 8x8x8mm 3x hose barb Ø8 mm - for gas hose
    1,69 €
    T-piece 8x8x8mm 3x hose barb Ø8 mm - for...

    Fits a Ø8mm gas hose and must be used in conjunction with a hose clamp to ensure a tight seal. Inner diameter: Ø5mmOuter diameter: Ø8mmOutlet connection: Ø8mm Hose barbInput connection: Ø8mm Hose BarbMaterial: SteelPressure class: EN16436 Class 2 (max. 10 bar)

    1,69 €
    IN STOCK
  • Straight Adapter Coupling: Pipe Ø8mm x hose barb Ø8mm
    1,84 €
    Straight Adapter Coupling: Pipe Ø8mm x...

    Application: Vapor gas applications: Adapter coupling from Ø8mm compression coupling to Ø8mm gas hose for low pressure (max. 10 bar) .  Brand: GOKOuter diameter: Ø8mmOutput connection: Ø8mm compression + swivelInput connection: Ø8mm Hose barbMaterial: BrassPressure class: EN16436 Class 2 (max. 10 bar)

    1,84 €
    IN STOCK
  • Stop plug / sealing plug 8mm - for sealing 8mm compression connection
    2,20 € 2,44 € -10%
    Stop plug / sealing plug 8mm - for sealing...

    This stop plug is intended to be able to cap / seal an 8mm compression fitting.Often used on, for example: Reca quick-closing valves  Brand: GOKMaterial: Brass

    2,20 € 2,44 € -10%
    Reduced price!
    IN STOCK
  • Plug-in nozzle Ø8mm hose barb for quick coupling
    2,95 €
    Plug-in nozzle Ø8mm hose barb for quick...

    Application: Connection to a quick coupling. Fits a Ø8mm gas hose on one side and a quick coupling on the other.  UPC Number: 8717081002367Inner diameter: Ø5mmOuter diameter: Ø8mmMaterial: BrassPressure class: EN16436 Class 2 (max. 10 bar)

    2,95 €
    IN STOCK
  • Coupling piece 8mm compression x G1/4” Male thread
    3,39 €
    Coupling piece 8mm compression x G1/4”...

    Straight coupling with male thread G 1/4" NPTF x 8mm Compression connectionWidely used on for example: Entrance of CAVAGNA 758TW Pressure regulator and all kinds of other pipes.  Inner diameter: Ø6mmOutput connection: Ø8mm compression + swivelInput connection: 1/4" NPT Male (±13mm)Spanner size: 17mm

    3,39 €
    IN STOCK
  • Straight compression coupling Ø8mm x hose barb Ø8mm
    3,81 €
    Straight compression coupling Ø8mm x hose...

    Fits on an LPG pipe Ø8mm on the one hand and Ø8mm gas hose on the other hand and must be used in combination with a slim clamp for a good seal.  Brand: GOKOuter diameter: Ø8mmOutput connection: Ø8mm compression + swivelInput connection: Ø8mm Hose barbMaterial: BrassPressure class: EN16436 Class 2 (max. 10 bar)

    3,81 €
    IN STOCK
  • Coupling piece 8mm compression x G3/8” Male thread
    4,54 €
    Coupling piece 8mm compression x G3/8”...

    Straight coupling with male thread G 3/8" NPTF x 8mm Compression connectionWidely used on for example: Output of CAVAGNA 758TW Pressure regulator Inner diameter: Ø6mmOutput connection: Ø8mm compression + swivelInput connection: 3/8" NPT Male (±16mm)Spanner size: 19mmMaterial: Brass

    4,54 €
    IN STOCK
  • T-stuk LPG Leiding 3 x 8mm
    4,84 € 6,05 € -20%
    Connection LPG Pipe 2 x 8mm compression...

    With this connector you can interconnect 2 x 8mm (copper) pipes.Sealing with 6mm compression ring and swivel (M12x1)  Inner diameter: Ø8mmOutput connection: Ø8mm compression + swivelInput connection: Ø8mm compression + SwivelSpanner size: 14mmMaterial: BrassPressure class: Up to 30 bar

    4,84 € 6,05 € -20%
    Reduced price!
    IN STOCK
  • Coupling piece LPG pipe Ø8mm M12x1 x Ø10mm M14x1 swivel
    5,45 € 6,05 € -10%
    Coupling piece LPG pipe Ø8mm M12x1 x Ø10mm...

    With this coupling piece you can interconnect Ø8mm M12x1 x Ø10mm M14x1 pipes. See image for further illustration.With 2x swivel and 2 x compression ring  Input connection: Ø8mm compression + swivelOutput connection: Ø10mm compression + swivelMaterial: BrassPressure class: Up to 30 bar

    5,45 € 6,05 € -10%
    Reduced price!
    IN STOCK
  • Coupling piece Shell G.5 Kombi-Soft W21.8 LH x 1/4” NPT external - With rubber sealing ring for gas bottle
    7,16 € 8,95 € -20%
    Coupling piece Shell G.5 Kombi-Soft W21.8...

    Straight coupling with male thread G 1/4" NPTF x Shell G.5 W21.8 LHOften used on, for example: Gas bottle with Shell connection, Icm quick coupling with 1/4" NPT female thread  Inner diameter: Ø4mmOutput connection: 1/4" NPT Male (±13mm)Input Connector: SHELL-Kombi Soft G.5 (W21.8 x 1/14 lh)Spanner size: 30mmMaterial: Brass

    7,16 € 8,95 € -20%
    Reduced price!
    IN STOCK
  • GOK Coupling piece 2x Ø8 mm Angled - Pipe connection Compression coupling
    7,50 €
    GOK Coupling piece 2x Ø8 mm Angled - Pipe...

    Can be combined with:- Copper LPG pipe Ø8mm- Plastic LPG pipe with Ø8mm connections (KF-0002, XD-4, XD-5)Brand: GOKInner diameter: Ø8mmOutput connection: Ø8mm compression + swivelInput connection: Ø8mm compression + swivelSpanner size: 17mmMaterial: BrassPressure class: Up to 30 bar

    7,50 €
    IN STOCK
  • T-stuk LPG Leiding 3 x 8mm
    7,74 € 9,68 € -20%
    T-Piece LPG Pipe 3x 8mm Compression...

    With this T-piece you can connect 3 x 8mm (copper) pipes.  Inner diameter: Ø8mmOutput connection: Ø8mm compression + swivelInput connection: Ø8mm compression + swivelSpanner size: 14mmMaterial: BrassPressure class: Up to 30 bar

    7,74 € 9,68 € -20%
    Reduced price!
    IN STOCK
  • Hansun Quick coupling Male x 1/4” NPT female with non-return valve
    8,43 € 9,92 € -15%
    Hansun Quick coupling Male x 1/4” NPT...

    Hansun Quick Coupling Male x 1/4” NPT FemaleWith non-return valve. When disconnected, the coupling closes.Often used on, for example: Gas bottle with Shell connection, Heftruk and in combination with quick coupling Female and Coupling piece Shell G.5 Kombi-Soft W21.8 LH x 1/4” NPT external. Outer diameter: Ø14mmOutput connection:...

    8,43 € 9,92 € -15%
    Reduced price!
    IN STOCK
  • LPG Gas Bottle Adapter Shell to 8mm compression fitting
    9,63 € 12,04 € -20%
    Shell coupling piece to x Ø8 mm...

    Used to connect a Ø8 mm LPG Pipe (Copper / Plastic) to a Gas bottle with a SHELL connection (left-hand thread) (W21.8 x 1/14 LH) Inner diameter: Ø4mmOutput connection: Ø8mm compression + swivelInput Connector: SHELL-Kombi Soft G.5 (W21.8 x 1/14 lh)Spanner size: 17mmMaterial: Brass

    9,63 € 12,04 € -20%
    Reduced price!
    IN STOCK
  • T-Piece Thermoplastic 3x 8mm LPG Pipe 3x connections - (FARO 8mm / Transfer Oil 1842)
    9,68 €
    T-Piece Thermoplastic 3x 8mm LPG Pipe 3x...

    Application: Used in combination with plastic LPG pipe Type FARO 8mm / Transfer Oil 1842 (= Ø8mm Copper), a Ø8mm compression ring (compression barrel) and a swivel Ø8mm to seal a connection. (NOT SUITABLE FOR LPG-FIT PLASTIC PIPE)

    9,68 €
    IN STOCK
  • Brass Adapter Piece 1/2" UNF x Ø8mm compression
    9,95 €
    Brass Adapter Piece 1/2" UNF x Ø8mm...

    Makes it possible to connect Ø8mm LPG-Pipe to a 1/2" UNF filling connection and / or the inlet of a 4-hole LPG-Tank (on elbow)  Inner diameter: Ø6mmSpanner size: 22mmOutput connection: Ø8mm compression + swivelInput Connector: 1/2UNF - 3/4-16 SAE 45°Flare Female (19mm)

    9,95 €
    IN STOCK
  • FARO T-piece for 3x Plastic LPG Pipe Ø6 mm KF-0001 / Transfer Oil 1841 / Faro 6mm
    10,89 €
    FARO T-piece for 3x Ø6mm Plastic LPG Pipe...

    Spanner size: 17mmMaterial: BrassPressure class: max. 30 barCan be combined with:- Plastic Pipe type KF-0001 / Transfer Oil 1841 / Faro 6mm

    10,89 €
    IN STOCK
  • Hansun Quick Coupling Female x 1/4” NPT female with non-return valve
    17,28 € 20,33 € -15%
    Hansun Quick Coupling Female x 1/4” NPT...

    Hansun Quick Coupling Female x 1/4” NPT femaleWith non-return valve. When disconnected, the coupling closes.Often used on, for example: Gas bottle with Shell connection, Lift pressure and in combination with quick coupling Male and Coupling piece Shell G.5 Kombi-Soft W21.8 LH x 1/4” NPT external.  Outer diameter: Ø27mmOutput...

    17,28 € 20,33 € -15%
    Reduced price!
    IN STOCK
  • T-Piece 3x 1/2" UNF 3x External Thread for Filling Hose
    20,69 € 22,99 € -10%
    T-Piece 3x 1/2" UNF 3x External Thread for...

    Can be used to fill 2x LPG tanks / Gas bottles at the same time.  Inner diameter: Ø10mmCoupling & Thread: 1/2UNF - 3/4-16 SAE 45°Flare Male (19mm)Output Connection: 1/2"UNF - 3/4"-16 SAE 45°Flare Male (19mm)Input Connector: 1/2UNF - 3/4-16 SAE 45°Flare Male (19mm)Material: BrassPressure class: Up to 30 bar

    20,69 € 22,99 € -10%
    Reduced price!
    IN STOCK
  • T-Piece 3x 1/2"UNF 2x Outer Thread 1x Swivel in Centre Position for LPG Filling Hose
    21,77 € 24,19 € -10%
    T-Piece 3x 1/2"UNF 2x Outer Thread 1x...

    T-Piece with 3x 1/2" UNF Coupling: 2x External thread + 1x Swivel with internal thread on side arm.Can be used to fill 2x LPG tanks / Gas bottles at the same time.  Inner diameter: Ø10mmSpanner size: 22mmOutput Connection: 1/2"UNF - 3/4"-16 SAE 45°Flare Female (19mm)Input Connector: 1/2UNF - 3/4-16 SAE 45°Flare Male (19mm)Material:...

    21,77 € 24,19 € -10%
    Reduced price!
    IN STOCK
  • T-Piece 3x 1/2"UNF 2x Outer Thread 1x Swivel in Centre Position for LPG Filling Hose
    21,77 € 24,19 € -10%
    T-Piece 3x 1/2"UNF 2x Outer Thread 1x...

    T-Piece with 3x 1/2" UNF Coupling: 2x Male thread + 1x Swivel with female thread On Middle Leg.Can be used to fill 2x LPG tanks / Gas bottles at the same time. Inner diameter: Ø10mmSpanner size: 22mmOutput Connection: 1/2"UNF - 3/4"-16 SAE 45°Flare Female (19mm)Input Connector: 1/2UNF - 3/4-16 SAE 45°Flare Male (19mm)Material:...

    21,77 € 24,19 € -10%
    Reduced price!
    IN STOCK
  • Hansun Quick Coupling Set x 1/4"NPT with Check Valve + Optional Fittings: Shell and 8mm Compression
    24,99 € 29,40 € -15%
    Hansun Quick Coupling Set (Male+Female) x...

    Often used in combination with, for example:- Gas bottle with shell connection- On a forklift truck with a gas bottleWhen disconnected, the quick couplings close.Choose the optional coupling pieces to be able to connect with a Shell connection (gas bottle) on the one hand and an 8mm compression (8mm pipe) on the other.   Outer diameter:...

    24,99 € 29,40 € -15%
    Reduced price!
    IN STOCK
  • LPG Non-Return Valve Ø8 mm M14x1 - High pressure (max 30bar) Liquid LPG Non-return valve
    32,67 €
    LPG Non-Return Valve Ø8mm M14x1 - High...

    Often used when connecting the outputs of two LPG Tanks. Serves to prevent the LPG from flowing back from one tank to the other tank. RDW requirement.  Approval number: E3 67R-0158470Inner diameter: Ø8mmOutput connection: Ø8mm compression + swivelInput connection: Ø8mm compression + swivelSpanner size: 19mmMaterial:...

    32,67 €
    IN STOCK
  • GOK T-piece with diverter valve 3x M20 - For 2 gas bottles
    40,29 € 44,77 € -10%
    GOK T-piece with diverter valve 3x M20 -...

    With this T-piece you can connect 2 gas bottles at the same time to your Pressure Regulator or to High Pressure Gas Filter with a single M20x1.5 connection on the input.   Brand: GOKOutput connection: M20 x 1.5 rh Gland + Sealing ringInput connection: M20 x 1.5 rh Male threadSpanner size: 23mmMaterial: BrassPressure class: Up to 25 bar

    40,29 € 44,77 € -10%
    Reduced price!
    IN STOCK
Showing 1 - 27 of 27 items
